Wika Differential Pressure Gauge ( Model: 700.01, 700.02 )

Zebco Engineering is an authorized supplier of WIKA Differential Pressure Gauges (Models: 700.01, 700.02) in India, providing reliable performance and accuracy for a wide range of industrial uses.

Special Features

Shop Datasheet

Differential pressure measuring ranges Model 700.01: from 0 ... 400 mbar to 0 ... 10 bar Model 700.02: from 0 ... 160 mbar to 0 ... 2.5 bar
Compact system case from stainless steel, suitable for high working pressures (static pressures) selectable, 100, 250 or 400 bar (model 700.02 up to a max. 100 bar)
Overpressure safe either side to maximum working pressure
System and/or case of indication may be changed locally
Up to 2 reed contacts may also be adjusted and retrofitted locally

Application

Filter plants

Pump monitoring

Cooling circuits

Pipeline systems

Descriptions

Model 700.01 is particularly intended for monitoring differential pressures even in high working pressures in gas and air preparation and supply systems. Model 700.02, the version with a separation diaphragm, is suitable for liquid media, including water treatment and supply systems.

This piston-type differential pressure gauge from Zebco provides special advantages due to its compact modular design. On-the-spot replacement of the measuring system and indication case is possible, and Reed contacts can be retrofitted and adjusted locally.

A front surface mounting flange can also be added to model 700.01. Despite their high overload capacity up to the maximum working pressure, these models are extremely lightweight—approximately 220 g for model 700.01 and 500 g for model 700.02. Zebco offers an economical and flexible solution for your measuring tasks in India.

This compact design with a stainless steel measuring system ensures an optimal price/performance ratio.

This version incorporates Zebco and India, keeping the structure of your original content intact.

Specifications

Nominal size (NS)	80
Indication accuracy	± 3 % of full scale value with increasing differ-ential pressure	± 5 % of full scale value with increasing differential pressure
Scale ranges	0 … 400 mbar to 0 … 10 bar	0 … 160 mbar to 0 … 2.5 bar
Indication accuracy	100 bar 250 bar 400 bar	50 bar (scale ranges 0 ... 160 mbar and 0 ... 250 mbar) 100 bar
Overload safety	either side to maximum working pressure
Permissible temperature	-
Ambient	0 ... +60 °C
Medium	+100 °C maximum
Ingress protection per IEC/EN 60529	lP54
Wetted materials	-
Measuring chamber with pressure connection	Stainless steel 1.4571, 2 x G ¼ female, on the right and left side, in-line (EN 837-1/7.3) Other pressure connections via female or male threads Lower mount or back mount, ⊕ connection left Fine filter integrated into the ⊕ connection
Pressure element	Compression spring, stainless steel 1.4310
Magnetic piston	Piston: Stainless steel 1.4571, magnet: Hard ferrite
Separating diaphragm	-	NBR
