Wika Precision Digital Pressure Gauges
(Model: CPG1500)

ebco Engineering LLP is an authorized supplier of WIKA's CPG1500 digital pressure gauge, offering high-precision measurements up to 0.025% accuracy. Ideal for calibration and industrial applications.

Special Features

Shop Datasheet

Measuring ranges between 0 ... 10,000 bar [0 ... 150,000 psi] and also vacuum and absolute pressure measuring ranges are available.
Accuracy: up to 0.025 % (incl. calibration certificate)
Intrinsically safe version
Logger function with up to 50 measured values per second
Communication with WIKA-Cal software via Bluetooth®

Application

Oil and gas industry

Maintenance and service facilities

Calibration service companies and service industry

Simple calibrations directly on-site

Pressure test

Descriptions

The model CPG1500 precision digital pressure gauge adopts the concept of an analogue pressure gauge and at the same time works with the precision of a digital calibration instrument. The instrument thus combines the accuracy of digital measurement technology with the simplicity of an analogue measuring instrument and features impressiveperformance and ease of use. The CPG1500 offers an accuracy of 0.1 % FS, 0.05 % FS or 0.025 % FS and is temperature-compensated in the range of -10 … +50 °C [14 ... 122 °F]. Measurements can be displayed in any of 26 pressure and 5 level units, or in custom units to avoid intricate conversions.

The measuring rate can be user-defined to match the type of measurement required. Standard applications usually use three measured values per second. If required, this measuring rate can also be set to 50 measured values per second.

Via an energy-saving function, the CPG1500 switches automatically into “sleep” mode, in this mode the battery life can be increased up to 2,500 hours.

Through the innovative menu navigation, simple operation is ensured. The clear display, with integral bar graph display and large text area, assists with the effective analysis of the widest variety of measuring locations. With the Min./Max. function, the minimum and maximum pressures can be accessed immediately and saved automatically.

Specifications

Pressure types	-
STANDARD	-
Gauge pressure	0 ... 10,000 bar [0 ... 150,000 psi]
Absolute pressure	0 ... 0.25 bar abs. to 0 ... 40 bar abs. [0 ... 0.35 psi abs. to 0 ... 400 psi abs.]
Vacuum and +/- measuring range	-0.25 ... +0.25 mbar to -1 ... 40 bar [-8 ... +8 psi to -14.5 ... 300 psi]
Accuracy	0.025 % FS 0.05 % FS 0.1 % FS 0.5 % FS
Connection location	Vertical mounting position, process connection lower mount
Adjustment	Offset and span factor adjustable
Mounting	-
Menu functions	Min./Max. alarm (visual) Power-off function Measuring rate Mean value filter Pressure rate Mean value (via adjustable interval) Level indication Tare offset Indication damping
Memory	Min./Max. memory Integrated data logger
Mean value interval	1 ... 300 seconds, adjustable
Measuring rate	Max. 50/s
Data logger	Cyclic logger ⇒ Automatic recording of up to 1,000,000 values Cycle time ⇒ Selectable from 1 ... 3,600 s in 1-second steps ⇒ Selectable with the measuring rate in the following steps: 1/s, 3/s, 10/s and 50/s
Battery status display	Symbol display with 4 bars indicates the battery status in 25 % steps.
Case	-
Rotatability	The case is rotatable by 330°
Ingress protection	IP65
Weight	Incl. batteries Incl. batteries	Approx. 680 g [1.5 lbs] Approx. 680 g [1.5 lbs]
