WIKA Authorized Supplier India · Data Sheet TM 52.01
WIKA Industrial Bimetal Thermometer Model A52.100/4 & R52.100/4
The entry-level process thermometer trusted across India's machine building, HVAC, vessel and piping industry. NS100 dial, compression fitting connection, accuracy class 1 per EN 13190. Short lead times from stock.
100 mm dial
Nominal Size
Class 1 · EN 13190
Accuracy
-30 … +500 °C
Scale Range
Design 4 · Compression fitting
Connection
About The Product
What Is the WIKA A52.100/4 & R52.100/4 Bimetal Thermometer?
The WIKA Model 52 is an entry-level industrial bimetal thermometer built to EN 13190, offering a stainless steel case and stem with accuracy class 1 at the 100 mm nominal size — the dial most commonly specified for panel and pipe-mounted process monitoring across machine building, vessel, piping and HVAC applications.
The /4 suffix identifies WIKA's design-4 connection: a compression fitting that slides freely on the stem, so the insertion length is set on installation rather than fixed at the factory. The A52.100/4 is the back (axial) mount, with the stem exiting directly behind the case; the R52.100/4 is the lower (radial) mount, with the stem exiting 90° below the case through an aluminium elbow.
Key Features at a Glance
- Bimetal coil measuring element, EN 13190 compliant
- Case, bezel ring, stem and process connection in stainless steel
- Accuracy class 1 at NS100 (class 2 below NS63)
- Aluminium dial, white with black lettering, adjustable pointer
- Compression fitting — adjustable insertion length on site
- IP43 ingress protection, max. 25 bar static at the stem
- Eleven standard scale ranges, °C / °F / dual °C-°F
- GOST, KazInMetr, BelGIM, UkrSEPRO, Uzstandard, CRN approvals (option)
Why specify model 52
Three Reasons Engineers Choose the WIKA A52 / R52 Series
The model 52 has been WIKA's reference entry-level bimetal thermometer for over a decade. Procurement teams specify it by name because it solves the three most common temperature-indication needs at once.
Class 1 Accuracy
NS100, 80, 63 and 160 all meet accuracy class 1 per EN 13190 — the tightest class offered on an entry-level dial thermometer.
Adjustable Insertion Length
Design-4 compression fitting slides on the stem, so the exact immersion depth is set on site rather than fixed at order time.
Wide Size & Mount Choice
Eight nominal sizes, back or lower mount, five connection designs, and eleven scale ranges cover almost every general industrial requirement.
Technical Data
Technical Specifications — WIKA Model A52.100/4 & R52.100/4
Complete parameters from WIKA data sheet TM 52.01 (02/2019). Contact Zebco Engineering for any configuration not listed.
| Parameter | Specification |
|---|---|
| Measuring element | Bimetal coil |
| Nominal size | 100 mm |
| Accuracy class | 1 per EN 13190 |
| Unit / scale | °C standard — °F or dual °C/°F on request |
| Case, bezel ring, stem, process connection | Stainless steel |
| Dial | Aluminium, white, black lettering |
| Pointer | Aluminium, black, adjustable |
| Window | Instrument glass |
| Ingress protection | IP43 per IEC/EN 60529 |
| Permissible operating pressure at stem | Max. 25 bar, static |
| Elbow behind case (R52 only) | Aluminium |
| Working range, continuous loading | Measuring range per EN 13190 |
| Working range, short-time (24h max.) | Scale range per EN 13190 |
Connection Design 4 — Compression Fitting (Sliding on Stem)
Insertion length l₁ is variable and set during installation; overall length L = l₁ + 40 mm. A sealing ring at the fitting maintains the process seal once tightened.
| Connection | Thread Length I (mm) | Spanner Width SW (mm) | Sealing Collar Ø D₄ (mm) | Stem Diameter Ø D (mm) |
|---|---|---|---|---|
| G ¼ B | 8 | 22 | 18 | 6 or 8 |
| G ½ B | 14 | 27 | 26 | 6 or 8 |
| M18 × 1.5 | 12 | 24 | 23 | 6 or 8 |
| ½ NPT | 19 | 22 | – | 6 or 8 |
| G ¾ B | 16 | 32 | 32 | 6 or 8 |
| ¾ NPT | 20 | 30 | – | 6 or 8 |
Available for nominal sizes 63, 80, 100 and 160 mm only. Standard male thread, plain stem, male nut and union nut designs are also available on request.
Measuring Ranges
Available Measuring Ranges
All ranges meet EN 13190 and are marked on the dial with two triangular indicators showing the measuring-range limits. Other scale ranges available on request.
| Scale Range (°C) | Measuring Range (°C) | Scale Spacing, NS100 | Error Limit ±°C, NS100 |
|---|---|---|---|
| -30 ... +50 | -20 ... +40 | 1 | 1 |
| -20 ... +60 | -10 ... +50 | 1 | 1 |
| 0 ... 60 | 10 ... 50 | 1 | 1 |
| 0 ... 80 | 10 ... 70 | 1 | 1 |
| 0 ... 100 | 10 ... 90 | 1 | 1 |
| 0 ... 120 | 10 ... 110 | 1 | 2 |
| 0 ... 160 | 20 ... 140 | 2 | 2 |
| 0 ... 200 | 20 ... 180 | 2 | 2 |
| 0 ... 250 | 30 ... 220 | 2 | 2.5 |
| 0 ... 300 | 30 ... 270 | 2 | 5 |
| 0 ... 400 | 50 ... 350 | 5 | 5 |
| 0 ... 500 | 50 ... 450 | 5 | 5 |
Applications
Where Is the WIKA A52 / R52 100/4 Used?
The combination of stainless steel construction, class-1 accuracy and an adjustable compression fitting makes this the default specification for general industrial temperature indication across India.
Machine Building
Local dial indication on skids, pumps, compressors and general industrial machinery.
Vessel & Piping
Direct-reading thermometers on tanks, headers and pipe runs, with or without a thermowell.
Heating & HVAC
Boiler, calorifier and district-heating circuits needing a robust field-proven dial.
Process Skids
Adjustable insertion length suits OEM skid packages where immersion depth is confirmed on site.
Model Comparison
WIKA A52.100/4 vs. R52.100/4 — Which Mount Do You Need?
Both variants share identical measuring element, accuracy, case material and connection hardware. The difference is purely how the stem exits the case relative to the dial face.
| Feature | A52.100/4 — Back Mount | R52.100/4 — Lower Mount |
|---|---|---|
| Stem orientation | Axial — straight out behind the dial | Radial — 90° below the dial, via elbow |
| Best for | Straight pipe runs, vessel walls viewed head-on | Vertical pipework, top-entry vessel connections |
| Elbow behind case | Not applicable | Aluminium |
| Spacer option | Available for process temp. from 300°C | Not applicable |
| Weight (approx.) | 0.250 – 0.290 kg | 0.330 kg |
| Case, stem, connection material | Stainless steel | Stainless steel |
| Accuracy class | 1 per EN 13190 | 1 per EN 13190 |
Not sure which mount is right for your installation? Call Zebco Engineering at +91 98982 26321 — our application engineers will recommend the right configuration.
Approvals & Certifications
Global Approvals for WIKA Model 52
Regional metrology approvals available as options — suitable for procurement under CIS-region and export project specifications.
GOST
Metrology, measurement technology, Russia.
KazInMetr / MTSCHS
Metrology & commissioning permission, Kazakhstan.
BelGIM
Metrology, measurement technology, Belarus.
UkrSEPRO
Metrology, measurement technology, Ukraine.
Also available: Uzstandard (Uzbekistan) and CRN safety approval (Canada). A 2.2 test report is available as an option. Verify current approvals with the manufacturer before ordering.
Selection Guide
How to Configure Your WIKA A52 / R52 Thermometer
Six parameters define your order. Zebco Engineering can assist with any selection step.
Mount Type
A52 back mount (axial) for in-line viewing, or R52 lower mount (radial) for vertical/top-entry connections.
Nominal Size
25 to 160 mm. NS100 offers the best balance of readability and accuracy class 1.
Connection Design
Standard thread, plain stem, male nut, union nut, or design-4 compression fitting.
Process Connection
G¼B, G½B, G¾B, M18x1.5, ½ NPT or ¾ NPT — matched to your process port.
Scale Range
Choose from eleven standard ranges, -30…+50°C up to 0…+500°C, or specify a custom range.
Insertion Length
Variable with the compression fitting — confirm final immersion depth on site.
Industries We Serve
Zebco Engineering Serves All Major Industries Across India
From Gujarat's industrial estates to Maharashtra's chemical hubs and Delhi NCR's machine building clusters — Zebco delivers WIKA temperature gauges wherever precision measurement is needed.
Why Choose Us
Why India's Engineers Rely on Zebco Engineering
An authorized WIKA distributor in India — your single-source partner for genuine WIKA thermometers with expert support and fast delivery from stock.
Authorized WIKA Dealer
100% genuine instruments with factory documentation and full traceability — no grey market risk.
Configuration Expertise
Our engineers help you select the right mount, connection and scale range for your application.
Competitive Pricing
Best-value quotations, bulk pricing for OEMs and EPCs, flexible commercial terms.
Pan India & Global Delivery
Serving all major Indian industrial cities plus Middle East and South/Southeast Asia exports.
95% Order Fulfillment
Zebco delivers WIKA A52.100 & R52.100 temperature gauges with a 95% on-time fulfillment rate.
Complete Documentation
Test reports and certificates supplied as standard for audit-ready procurement.
Delivery
Pan India & Global Supply
Zebco Engineering delivers genuine WIKA A52.100/4 & R52.100/4 bimetal thermometers reliably to every industrial zone in India and internationally.
🇮🇳 Pan India Delivery
Supplying WIKA thermometers to India's major machine building, chemical, and industrial automation clusters.
🌐 Global Export
International supply with export documentation, commercial invoices, and compliance certificates.
FAQ
Frequently Asked Questions
Expert answers for engineers and procurement teams — structured for search and AI answer engines.
Both share the same NS100 dial, bimetal element, accuracy class and design-4 compression fitting. The A52.100/4 is a back (axial) mount, with the stem exiting straight behind the case. The R52.100/4 is a lower (radial) mount, with the stem exiting 90° below the case via an aluminium elbow.
Design 4 is a compression fitting that slides freely on the stem. The insertion length is set on site, then the fitting is tightened and sealed with a sealing ring — offered for NS 63, 80, 100 and 160 in G¼B, G½B, G¾B, M18x1.5, ½ NPT and ¾ NPT.
Accuracy class 1 per EN 13190 — the tightest class in the model 52 range, shared with NS63, NS80 and NS160.
Eleven standard scale ranges from -30…+50°C up to 0…+500°C, in °C, °F, or a dual °C/°F scale. Custom scale ranges are available on request.
For NS100 (and NS63/80/160), the permissible operating pressure at the stem is a maximum of 25 bar, static.
Not strictly, for low-pressure, low-viscosity, low-flow applications — but a thermowell is generally recommended so the thermometer can be exchanged or calibrated without interrupting the process.
Yes. Zebco Engineering LLP is an authorized WIKA distributor in India, supplying pan India to all major industrial zones, plus international export to the Middle East, Southeast Asia, and South Asia with complete documentation. Contact +91 98982 26321 or sales@zebcoeng.com.
