WIKA OEM Pressure Sensor for Industrial Applications Models O-10 (T) & O-10 (5)

O-10 (T) is the standard version: ranges 0–6 to 0–600 bar gauge, 2× overload (3× on request), six output signal options including 0–10V and 0–5V, five electrical connection types, medium temperature –30 to +100°C, accuracy ≤±1.2% of span. O-10 (5) is the water-safe version: limited to 0–6 to 0–40 bar gauge ranges, 5-fold overload safety, condensation-tight case, three electrical connections (M12, Metri-Pack, cable), four output signals (no 0–5V or 0–10V), medium temperature –40 to +100°C (wider cold limit), accuracy ≤±2.0% of span. The O-10 (5) is specifically recommended by WIKA whenever water is used as the measuring medium.

WIKA designed the O-10 specifically for OEM production environments with annual requirements exceeding 1,000 units per article number. The 50-unit MOQ reflects the production-scale manufacturing and batch testing approach WIKA uses for this sensor — lower batch sizes would not align with the product's cost optimization model. If you need fewer than 50 units, WIKA's A-10 pressure transmitter (data sheet PE 81.60) has no minimum order quantity and covers similar pressure ranges and output signals. Zebco Engineering can help you select the right model for your quantity requirement.

Included as standard: CE (EU Declaration of Conformity — EMC Directive, Pressure Equipment Directive, RoHS Directive); EAC (Eurasian Economic Community EMC directive); GOST (Russia metrology); KazInMetr (Kazakhstan metrology); UkrSEPRO (Ukraine metrology); CRN (Canada safety). Optional: UL/cULus (USA and Canada — electrical safety and overpressure). China RoHS compliant per manufacturer's information. MTTF is greater than 100 years. This broad standard certification package makes the O-10 well-suited for OEM equipment exported to multiple global markets.

Yes — the WIKA O-10 is one of the few WIKA pressure sensors supporting the Delphi Metri-Pack series 150 3-pin connector (IP67) — commonly used in automotive, mobile machinery, and building controls applications. O-10 (T) also supports angular DIN 175301-803 A (IP65), angular DIN 175301-803 C (IP65), M12×1 4-pin circular (IP67), and cable outlet unshielded or shielded (IP67). O-10 (5) supports M12×1 4-pin (IP65), Metri-Pack (IP67), and cable outlet unshielded (IP67). Note: Metri-Pack on O-10 (T) is only available from the 0–60 bar measuring range upward.

Water hammer is a transient pressure wave caused by rapid valve closure, pump start/stop, or sudden flow changes in water pipework. These spikes can reach 5–10 times the normal system pressure within milliseconds. A standard pressure sensor with 2× overload (like O-10 T) would be overpressured and permanently damaged or drift-shifted by such events. The O-10 (5)'s 5× overload safety absorbs these transients without sensor damage or accuracy degradation. WIKA also adds a condensation-tight case because water system installations — particularly in building services — are often in damp environments where standard IP65/IP67 is not enough without the condensation-tight case design.

Yes. WIKA explicitly states the O-10 can be delivered with customer-specific labelling, including company logo and instrument designation. This is a key feature for OEM manufacturers who want their brand on the sensor embedded in their equipment — rather than a visible WIKA label that reveals the sensor supplier to end customers. This custom labelling capability, combined with the OEM-volume pricing structure, makes the O-10 the ideal platform for equipment manufacturers requiring branded pressure sensing solutions. Contact Zebco Engineering to discuss labelling specifications and minimum quantities for custom-labelled orders.

Wetted parts: stainless steel 316L and 13-8 PH (precipitation-hardening) grade stainless steel for the high-pressure sensing element. Non-wetted parts: stainless steel 316L and PBT GF30 (glass-fibre reinforced PBT plastic for connector body). Cable outlet material: PVC. Sealing: NBR (standard for DIN 3852-E and SAE) or FPM/FKM (option). Yes — oil- and grease-free versions of the O-10 are available on request. Specify at time of ordering for applications involving oxygen, food-grade requirements, or media incompatible with synthetic oil.

O-10 (T): non-linearity ≤±0.5% BFSL, accuracy ≤±1.2% of span at reference conditions, temperature error ≤±1.5% of span (0–80°C), long-term stability ≤±0.3%/year. O-10 (5): non-linearity ≤±0.5% BFSL, accuracy ≤±2.0% of span, temperature TC of zero typical 0.3%/10K. Compared to A-10: A-10's max measured error for ranges ≥0.6 bar is ≤±1% (standard) or ≤±0.5% (0.25% NL option) — slightly better than O-10 (T). S-10 achieves non-linearity ≤±0.2% BFSL — tighter than O-10. For OEM applications where ≤±1.2% is acceptable (hydraulics, pumps, building services), O-10 provides excellent price-performance in volume. For tighter accuracy, specify A-10 or S-10.

Yes. Zebco Engineering LLP is an authorized WIKA distributor in India, supplying WIKA O-10 to OEM manufacturers across all major Indian industrial clusters — Mumbai, Pune, Ahmedabad, Surat, Vadodara, Delhi NCR, Chennai, Bengaluru, Hyderabad, Kolkata, Rajkot, Ludhiana, and Coimbatore. International OEM export supply to the Middle East, Southeast Asia, and South Asia is also handled with complete documentation (CE, EAC, GOST, optional UL/cULus). Minimum order: 50 units per article number. Contact: +91 98982 26321 or sales@zebcoeng.com.
